Technische Daten zu "Kugelhahn HKM-400"
| ABMESSUNGEN | VORRAT | |||||||||
| D | L1 | L | H | R | SW | kg/st | 316 | |||
| NW | " | mm | mm | mm | mm | mm | mm | BSP | NPT | |
| NW 8 | 1/4" | 6 | 40 | 80 | 50 | 80 | 22 | 0.405 |
V |
o |
| NW 10 | 3/8" | 10 | 42 | 80 | 74 | 112 | 27 | 0.600 |
V |
o |
| NW 15 | 1/2" | 14 | 59 | 110 | 64 | 130 | 32 | 1.020 |
V |
o |
| NW 20 | 3/4" | 19 | 64 | 120 | 71 | 130 | 41 | 1.465 |
V |
o |
| NW 25 | 1" | 24 | 78 | 140 | 83 | 160 | 50 | 2.765 |
V |
o |
V = Vorrat O = auf Anfrage ab Werk
